IG-820 是一支台灣廠商熱銷世界的二維條碼掃描器 分類：電子業 適用範圍：
| 光源 | White light 635nm LED±5nm |
| 掃瞄線 | Single line |
| 感應器 | Linear CCD |
| 掃描景深 | Up to 550mm@0.5mm(20mil), PCS90,Code39 |
| 解晰度 | 0.1mm(4mil)@PCS90% |
| 環境光抗度 | 100,0000 Lux Max. |
| 掃描器電壓 | Li-Ion 3.7V 2600mA |
| 接收器電壓 | DC +5V ±5%(Adaptor) |
| 掃瞄器耗電量 | |
| Power On | 190mA |
| Stand by | 50mA |
| Operation | 150mA |
| Sleep | 6mA |
| 接收器耗電量 | |
| Power On | 95mA |
| Stand by | 55mA |
| Operation | 70mA |
| 指示燈狀態 | Beeper and LED |
| 掃描速度 | Smart detection up to maximum 500 scans/sec |
| 掃描角度 | 30° ± 3° |
| Pitch | ±10°~60°(±5°) |
| Skew | ± 60°(±5°) |
| 藍牙 | Bluetooth V2.1 EDR |
| 無線頻寬 | 2.402GHz~2.480GHz |
| 傳輸距離 | up to 100m in open space |
| 無線功率 | Class 1 (under 20 dBm) |
| 操作温度 | 0°C to 50°C (32°F to 122°F) |
| 儲存溫度 | -20°C to 70°C (-4°F to 158°F) |
| 相對温度 | 20% to 95% (Non-condensing) |
| 防水防塵 | IP42 |
| 落摔 | 1.20m drops on Concrete Surface |
| 外殼材料 | ABS & Rubber |
| 介面 | USB |
| 線材 | Straight 5 FT. |
| 接口 | RJ45 Phone Jack Connector |
| 掃描器重量 | Approx. 165g |
| 接收器重量 | Approx. 170g |
| 充電時間 | |
| 充飽電讀取次數 | |
| 顏色 | Black/Gray |
| 掃描器尺寸 | 73.5mm (W) x173 mm (W) x 76.2 mm (H) |
| 接收器尺寸 | 103.6 mm (W x 135 mm (D) x 83.6 mm (H) |
| 腳座尺寸 | |
| 使用壽命(計算) |
